The CiMotion is truly a tray sealing system like no other. Do not let its small size fool you. The CiMotion is designed to produce meal trays and can be placed even in the smallest of facilities. The CiMotion runs on 110V which adds to its versatility. But the real feature that puts our CiMotion into its' own category is the fact that it has Gas Flush capabilities.
All controls are located at the front of the CiMotion and the touch panel provides easy access to the sealing parameters, take-away food tray selection, and tool change. Our temperature controller individually controls the temperature of each sealing element thus creating the optimal sealing environment.
The real beauty of the CiMotion is the turntable operation. While one meal tray is being sealed another new tray is being loaded onto the turntable which is then rotated into the sealing chamber. This feature allows one operator as close to continuous operation as possible.
Tool changes from one tray style to another are quick and easy. Convenient access from the front allows the operator to make the switch in less than 5 minutes.
Trays that work with our CiMotion:
Rectangular: 1171 - 2171 - 2187 - 2200 - 2220 - 2208 - 2227 Circular: 0080 - 0095 - 0123 - 0124 - 0126 - 0160 Special: 0503 - 1085 - 2182 - CP4S
Rectangular trays | Tray 1171 | Tray 2171 | Tray 2187 | Tray 2200 | Tray 2220 | Tray 2208 | Tray 2227 |
---|---|---|---|---|---|---|---|
Trays per tool | 2 trays | 2 trays | 2 trays | 1 trays | 1 trays | 1 trays | 1 trays |
Film width | 240 | 240 | 240 | 210 | 190 | 210 | 240 |
Circular trays | Tray 0080 | Tray 0095 | Tray 0123 | Tray 0124 | Tray 0126 | Tray 0160 |
---|---|---|---|---|---|---|
Trays per tool | 6 trays | 3 trays | 2 trays | 2 trays | 2 trays | 1 trays |
Film width | 240 | 130 | 190 | 190 | 190 | 210 |
Special trays | Tray 0503 | Tray 1085 | Tray 2182 | Tray CP4S |
---|---|---|---|---|
Trays per tool | 2 trays | - | 2 trays | 1 trays |
Film width | 240 | - | 240 | 160 |
Incorporated safety features:
- Low compressed air supply alert
- Easily accessible power switch and E-Stop
- 2 button operation assures that operator’s hands are safe
- Position detector to ensure proper tray position before sealing
- Tamper proof panel/cover detector
- Up to 50-150 Meals per Day
- Does not cut the film to the shape of the tray (Straight cut)
- Seal only
- Manual Operation
The professional product presentation you've always wanted is achieved with an affordable packaging solution ideal for new operations or low volume enterprises. The CiMicro Starter kit is the perfect tray sealing machine for personal chefs, test kitchens and start-up businesses. This meal packaging system allows for easy mold changes, which means that it is compatible with multiple sizes and styles of CPET food trays. Simply lower the lid of the sealer machine onto your meal tray and you will have a leak-proof seal in a matter of seconds.
Our Starter Kit which sells for $ 2,290.00 (plus applicable taxes and freight) includes:
- CiMicro Tray Sealer (110 Volts)
- Two cases of CPET or APET food trays from our 1171, 2171, 2187, 2200, 2208, or 2227 stock food tray program
- One roll of film
- One sealing frame
Bigger needs? Higher volume? Take a look at our Compact manual tray sealing machines.
- Up to 400-600 Meals per Day
- Does not cut the film to the shape of the tray (Straight cut)
- Seal only
- Manual Operation
- Holds 1 Roll of Film
The CLASSIC model food tray sealer is an ideal option for packaging both cold and warm meals in either APET or CPET trays. If your tray selection requires only one width of sealing film then this is the sealer to choose.
Each compartment of a the food tray is sealed separately with the CLASSIC tray sealer so you can be sure to avoid any redistribution of food during delivery. As an added bonus, the food trays are sealed to be leak-proof and work to keep your product fresh longer. Delivery and carrying home is easy.
Versatility in packaging at its best, you can change from one tray style to another in 2 seconds.
The CLASSIC
- Seals APET, CPET and PP trays in 2 seconds
- Holds one roll of film at a time
- Maximum tray size: 11.4 x 10 x 1.9 inches (289 x 254 x 49 mm) (Tray 2290-1E)
- Up to 400-600 Meals per Day
- Does not cut the film to the shape of the tray (Straight cut)
- Seal only
- Manual Operation
- Holds 2 Rolls of Film
The COMPACT MODEL II food tray sealer is an ideal option for packaging both cold and warm meals in either APET or CPET plastic to-go containers. If the food tray styles that you want to use require two different widths of film, this is the tray sealer to choose.
Each compartment of the meal container is sealed separately with the COMPACT MODEL II tray sealing machine so you can be sure to avoid any redistribution of food during delivery. As an added bonus, the food trays are sealed to be leak-proof and work to keep your product fresh longer. Delivery and carrying home is made easy for you and your customers with this food packaging system.
Versatility in packaging at its best, you can change from one style or size of tray to another in 2 seconds.
The COMPACT MODEL II MANUAL TRAY SEALER
- Holds two rolls of film of different widths at a time. Each roll is available to pull and seal at any time.
- Maximum tray size: 10.1" x 9.4" x 3.50" (256 x 238 x 89 mm)
- Seals the tray in 2 seconds
- Up to 400-600 Meals per Day
- Does not cut the film to the shape of the tray (Straight cut)
- Seal only
- Manual Operation
- Holds 3 Rolls of Film
- Seals 1/2 pan food service tray size (2325)
The COMPACT MODEL III manual food tray sealer is an ideal option for packaging both cold and warm meals in either APET or CPET food trays. If the food tray styles that you want to package require three different widths of film (from food service size down to airline-sized meals), the COMPACT MODEL III is the food tray sealing machine to choose.
Each compartment of the meal tray is sealed separately with the COMPACT MODEL III tray sealer so you can be sure to avoid any redistribution of food during delivery. The trays are sealed to be leak-proof and work to keep your product fresh longer. Delivery and carrying home becomes easier for your customers.
The COMPACT MODEL III
- Holds three rolls of sealing film of different widths at a time. Each roll is available to pull and seal at any time.
- Maximum tray size: 12.8" x 10.4" x 3.1" (325 x 264 x 79mm) (Tray 2325-1B)
- Smallest tray size: 6.7" x 3.85" x 1.3" (170 x 98 x 34mm) (Tray 1171-1B)
- Seals the tray in 2 seconds
This semi-automatic tray sealing machine is a tabletop model with die cut features. Very compact, the RAPIDA PLUS is a drawer style food tray sealer that seals and cuts the film around the food tray with a pneumatic piston. As you push in the drawer holding your meal-filled trays, the sealing film is automatically drawn over the trays and the machine does the rest of the sealing for you. When you remove the tray, peel away the excess film that has been die cut around the contour of the tray. This machine is designed to ensure that each compartment of the tray is sealed separately to ensure that no food is redistributed during delivery.
Many sealing frames (sealing moulds) are available with the RAPIDA PLUS, giving this tray sealing machine the versatility to seal meals of all shapes and sizes. Each mould can be purchased separately to fit with the trays you wish to seal. The temperature and sealing time are regulated to allow for the sealing of different types of film and trays.
The CiMatic GF Tray Sealing Machine has been designed to offer customers an automated system at an affordable price with a gas flush feature. The goal is to seal ready meal trays fast and effectively at speeds up to 20 per minute.
Tell us which food trays best suit your application from our selection below and we will set the temperature, production speed and pressure so that all you have to do is turn on the CiMatic and allow it to heat up. This automatic food packaging machine does all the work for you. All you have to do is place your delicious meals onto the conveyor and the to-go containers will be hermetically sealed to ensure a leak-proof transportation of your product. The lidding film will be straight cut between each tray, giving your meal the product presentation you've always wanted.
The CiMatic GF meal packaging machine also allows for quick tray mold changes. This means that you can seal a variety of different styles and sizes of trays with this one food packing machine.
Watch the attached video to see the CiMatic in action and for a demonstration of the mold changes.
Unique features of the CiMatic GF :
- Gas Flush feature
- Food trays are transported using a single pallet design, no joints.
- Changing from one tray size to another is easy.
- Motor is 1/4 HP with inverter.
- Jog conveyor backward and forwards for easy setup
- Aluminium - Stainless Steel Build
- 2 Locking Castors
- Working Height: 35i
- Emergency STOP button on operator control panel – easily accessible from either side of the loading station
- Safety guards are in place
The following parameters can be changed by the operator:
- Temperature
- Sealing Pressure
- Conveyor speed
Speed of sealing by tray series at a comfortable level for the operators.
- 2171 Series - *20 Trays/min
- 2187 Series - *20 Trays/min
- 2208 Series - *14 Trays/min
- 2227 Series - *15 Trays/min
- The speed is adjustable by the operator
The CiMatic Tray Sealing Machine has been designed to offer customers an automated system at an affordable price. The goal is to seal ready meal trays fast and effectively at speeds up to 20 per minute.
Tell us which food trays best suit your application from our selection below and we will set the temperature, production speed and pressure so that all you have to do is turn on the CiMatic and allow it to heat up. This automatic food packaging machine does all the work for you. All you have to do is place your delicious meals onto the conveyor and the to-go containers will be hermetically sealed to ensure a leak-proof transportation of your product. The lidding film will be straight cut between each tray, giving your meal the product presentation you've always wanted.
The CiMatic meal packaging machine also allows for quick tray mold changes. This means that you can seal a variety of different styles and sizes of trays with this one food packing machine.
Watch the attached video to see the CiMatic in action and for a demonstration of the mold changes.
Unique features of the CiMatic :
- Food trays are transported using single pallet design, no joints.
- Changing from one tray size to another is easy.
- Motor is 1/4 HP with inverter.
- Jog conveyor backwards and forwards for easy set up
- Aluminium - Stainless Steel Build
- 2 Locking Castors
- Working Height: 35i
- Emergency STOP button on operator control panel – easily accessible from either side of the loading station
- Safety guards are in place
The following parameters can be changed by the operator:
- Temperature
- Sealing Pressure
- Conveyor speed
Speed of sealing by tray series at a comfortable level for the operators.
- 2171 Series - *20 Trays/min
- 2187 Series - *20 Trays/min
- 2208 Series - *14 Trays/min
- 2227 Series - *15 Trays/min
- The speed is adjustable by the operator
Affordable, the CiMAP Mini is a tabletop vacuum tray sealing machine with gas injection for optimal shelf life. Ideal for preserving your foods in disposable meal containers (which are 100% recyclable and made up to 70% out of previously recycled water bottles), the CiMAP Mini allows you to achieve the clean-cut and professional look that you've always wanted for your product.
Simply place your filled meal trays into the mold in the drawer, push the drawer in and let the machine do the rest! An excellent presentation is achieved with a cutting system that follows the exact shape of the tray. The vacuum and gas injection function of the CiMAP Mini will seal your meal in such a way that the air will be pulled out of the tray and replaced by a gas mixture. The removal of oxygen from the meal tray will reduce growth of bacteria, keeping your food fresh longer.
Finally this machine allows for quick and easy mold changing with minimal tools, making it suitable for many types of trays and film.
A compact tabletop machine for MAP packaging with particular attention to hygiene and safety. The CiMap 2 is fitted with a vacuum sensor for a precise adjustment of vacuum and gas. The machine is extremely user-friendly. The drawer is installed on special guides that grant a smooth and comfortable movement. To change from one tray style to another is very easy and accessible through the front panel.
The P-SG 420 GF is the optimal table top tray sealing unit for small to medium productions where gas flush packaging is being used to increase the shelf life of your product. The small foot print of the unit allows for it to be placed easily within production facilities and test kitchens.
The unit is built in stainless steel, with a Teflon coated aluminum plate.
*Seal Only or Gas Flush
CiMa-Pak Stock Tray Tooling Set Up 3 Trays Per Cycle – 1171 Series, 2202 Series 2 Trays Per Cycle – 2171 Series, 2187 Series, 2200 Series, 2208 Series, 2220 Series 1 Tray Per Cycle – 2227 Series
Electrical version also available
Features
- Stainless Steel construction
- Digital Vacuum gauge
- Digital Control Panel with 25 programs
- Vacuum by percentage or time
- Manual lowering of the hood
- Vacuum pump: 25m³ / h
- Capacity for 8 trays in one cycle (Depending on your tray selection)
- Film Width: 17" (430mm)
- Die-Cut
Maximum Tray Dimensions: 1 Tray - 21" x 14.8" x 4" (537 x 375 x 100 mm) 2 Trays - 10" x 7" x 4" (256 x 175 x 100 mm) 4 Trays - 6.3" x 4.3" x 4" (162.3 x 108.3 x 100 mm) 8 Trays - TBD
The Unica 25 is designed for businesses looking to start up or ramp up their existing tray sealing production to a medium level of output. At the same time affording them the ability to seal larger tray styles for catering and family sized meals and portions. Largest tray size is 370 x 280 x 115mm (14.5 x 11 x 4.5”)
The tray sealer allows production to switch from one tray style to another with its easy and rapid tool change system, which is unavailable on smaller units. No tools required.
The Unica 25 is impressively built in stainless steel and aluminum, allowing for easy cleaning and up keep of the unit. It comes standard with a vacuum pump that is 25m³
CiMa-Pak Trays Tooling Set Up 3 Trays Per Cycle – 1171 Series, 2182 Series 2 Trays Per Cycle – 2171 Series, 2187 Series, 2200 Series, 2202 Series, 2208 Series, 2220 Series 1 Tray Per Cycle – 2227 Series, 2290 Series, 2325 Series
The SVR Turn is truly a most remarkable vacuum tray sealing machine. This semi-automatic modified atmosphere packaging (MAP) system is unique in the fact that the tooling where the trays sit rotates into the MAP vacuum/seal area. While one tray is being vacuum packaged the other tray is being removed and replaced with a new tray to be packaged. This process therefore speeds up your production.
As an added benefit, if you are currently using our standard SVR MAP Tray Sealer or our Easy MAP Tray Sealer the tooling is interchangeable. And, if you start with the SVR Turn you can always move the tooling to an Easy MAP Tray Sealer.
Features:
- Semi automatic vacuum/MAP sealing machine for preformed trays in PP, PE, PS, PET, AL etc. with manual rotary table that allows to load and unload trays while the machine performs the cycle
- Pressure sensor for vacuum and gas
- Teflon coated sealing plate
- Profile cutting to the tray size
- Digital temperature controller with PT 100 probe
- 10 storable programs (possibility to set sealing, vacuum, gas)
- Structure in stainless steel, aluminium and polythene
- Moulds made on tray samples for any shape
- Fast tool change
The Unica Skin Packaging machine is a great food packaging option for smaller levels of production. It was developed exclusively for skin packaging. Ideal for meats, smoked foods, seafood and frozen meals, skin packaging machines allow you to substantially extend the shelf life of your product by preventing the formation of ice crystals (freezer burning).
The control panel at the front of the Unica allows you to set different parameters such as vacuum intensity, film preheating and seal time. Once the parameters are set to your liking, simply place your meal tray into the mold in the drawer, push the drawer in and let the Unica do the rest!
For this machine, you can have a mould made for up to 4 trays per cycle. this depends on the size of your tray.
- 1 Tray: 300 x 210 x 100mm (11.8" x 8.3" x 4")
- 2 Trays: 210 x 148 x 100mm (8.3" x 5.8" x 4")
- 3 Trays: 80 x 210 x 100mm (3.1" x 8.3" x 4")
- 4 Trays: 110 x 148 x 100mm (4.3" x 5.8" x 4")
*When packaging with the Unica, make sure that your meal has been chilled.
The TVG Machine is a mid-sized MAP packaging machine that is made for increasing output and can handle larger-sized trays. It is made completely of stainless steel and is also easily movable. The TVG MAXI MAP Machine has an automatic start of the cycle with the push of the two start buttons (Safety feature), film trim rewinder, and an end-of-cycle tray lifter. If you have more than 1 tray style, this machine is perfect as it has the capability of storing 5 programs. This means with the click as a button, you can easily go from one tray to another after the tool change..
For this machine, you can have a mould made for up to 6 trays per cycle. This depends on the size of your tray:
- 1 Tray - 350 x 275 x 115mm (13.78" x 10.82" x 4.5")
- 2 Trays - 275 x 180 x 115mm (10.82" x 7" x 4.5")
- 3 Trays - 275 x 100 x 115mm (10.82" x 4" x 4.5")
- 4 Trays - 175 x 130 x 115mm (6.88" x 5" x 4.5")
- 6 Trays - 95 x 95 x 15mm (3.74" x 3.74" x 4.5")
- 6 Bowls - 95 Ø
The EASY model automatic vacuum tray sealer is economical and compact in size. It is designed for medium volume production levels and is simple to use and set up.
Sturdy and built in stainless steel, it is equipped with Teflon-coated sealing plates and a touch screen with 10 storable programs. This vacuum tray sealer with gas injection will optimize the shelf life of your products. It seals trays made of PP, PE, CPET, APET and aluminum.
The unit has been optimized to seal trays of various sizes (up to the family portion size 360 x 270 x 100 mm).
With the TSA 626 Vacuum Tray sealer the customer typically places the product into a tray (please see trays in our Tray Search Section) and the trays are placed into the infeed rails. The tray is then moved into the sealing section where the film is heated and sealed to the tray.
BENEFITS:
- Quick tool change = new size, shape, material
- Fast change over permits many packaging formats on one machine
- Short down time to change between formats
- Easy to use range of pre-made trays in numerous materials : CPET. APET, PP, EPS
- Excellent customer presentation
Features:
- Colour Touch Screen Panel 5.7”
- Stainless Steel Build AISI 304
- Vacuum by either MBARS or Time
- Film Advancement by two synchronized motors
- Film drive: Either by length or Optional Eye Mark
The FUTURA is a small footprint, automatic tray sealer machine which offers all of the features of our larger systems at a fraction of the cost. It can seal meal trays made of PP, PE, CPET, APET and Aluminum. This machine is available in a 'seal only' mode or a modified atmosphere packaging (MAP vacuum packaging) mode. Robust, compact, easy to use and economical, the FUTURA is designed for medium levels of production.
Features:
- Rapid-change mould system, making it possible to switch from one tray style to another within a few minutes and giving you great sealing versatility.
- Teflon-coated sealing plates.
- Stainless steel and aluminum structure.
- Sensors for vacuum and gas.
- Die cutting of the lidding film to the contour of the tray, giving your finished product a nice clean look.
- Possibility to use 2 chambers with different tools.
- As with any CiMa-Pak sealing system, all safety measures have been addressed in the high pressure, high temperature, and pinch zones.
Individual product programming – there are up to 10 different programs – is accessed through the operator interface well located on the front panel. The following parameters are modified through this Control Panel:
- Temperature
- Sealing time
- Dwell time
- Film advance for scrap rewind
- Please note that the output is dramatically reduced on the vacuum/gas models.
The FUTURA is a small footprint, automatic tray sealer machine which offers all of the features of our larger systems at a fraction of the cost. It can seal meal trays made of PP, PE, CPET, APET and Aluminum. This machine is available in a 'seal only' mode or a modified atmosphere packaging (MAP vacuum packaging) mode. Robust, compact, easy to use and economical, the FUTURA is designed for medium levels of production.
Features:
- Rapid-change mould system, making it possible to switch from one tray style to another within a few minutes and giving you great sealing versatility.
- Teflon-coated sealing plates.
- Stainless steel and aluminum structure.
- Sensors for vacuum and gas.
- Die cutting of the lidding film to the contour of the tray, giving your finished product a nice clean look.
- Possibility to use 2 chambers with different tools.
- As with any CiMa-Pak sealing system, all safety measures have been addressed in the high pressure, high temperature, and pinch zones.
Individual product programming – there are up to 10 different programs – is accessed through the operator interface well located on the front panel. The following parameters are modified through this Control Panel:
- Temperature
- Sealing time
- Dwell time
- Film advance for scrap rewind
Our TSA 826 Automatic Tray Sealer is especially designed for the packing of food products. The high rate of output (achieved by using a 202 cubic metre vacuum pump), easy programming, quick tooling change over and flexibility, explains the popularity of the TSA 826 Automatic Tray Sealer.
To compliment the already versatile nature of the TSA 826 this system comes complete with an eye mark sensor for printed film. Otherwise, with unprinted film the length of the tray is the determining factor for feeding the film.
Added Benefits:
- Easy to clean Thanks to the design of the machine, it can be cleaned easily
- Easy to operate The step by step program will guide you through the menu
- Improved product appearance By retaining the liquid and through the use of specially designed top films
Structure in Stainless Steel AISI 304. Vacuum by MBARS and Time, or both. Capacity for 2 ½ GN Tray. Capacity for 3 1/4 GN Trays. Capactiy for 4 1/8 GN Trays. Film dragging by two synchronized motors. Moulds adaptation chosen by the customer. Replaceable rings to adapt the tray to every manufacturer. Film progress mode: By Length - By Printed Stain. Power: 6 - 11 KW (According to the pumps).
When it comes to tray sealers speed can be the ultimate deciding factor. If you have a production deadlines to meet then speed can make or break your contract. Single lane production means that your product travels through the MAP/sealing section onto the exit conveyor and then, if available through a metal detector and labeler into the pack out section.
The 10” Touch Screen permits the operator (separate login per operator) to easily recall a previously stored program (up to 29 programs) or change the existing parameters of the program which is running. This means that at the beginning of a production run you can run at a slower speed to ensure that everything is running correctly then ramp up the cycle speed.
Equally impressive is the fact that you can use printed film to an eyemark or clear film to a predetermined length. And speeds are impressive. The film unwind is driven which adds to the speed and accuracy of film placement.
Cycle Speed: 16 cycles/min.*
Tooling Set-Up: #2171 #2187 #2200 #2208 #2227 #2325
5 Trays 5 Trays 4 Trays 4 Trays 4 Trays 2 Trays
A few other nice features:
- Integrated network connection
- Detector for end of roll as well as a break in the film
- Structure manufactured from AISI Type 304 Stainless
- Software adaptable for additional peripherals i.e.: tray destacker, doser, labelers, and much more.
- Pneumatic system by Festo
- Electronic components such as: frequency inverter, drives, plc, and touch screen are all supplied by Schneider
